| 起源の場所: | 中国 |
| ブランド名: | MIROC |
| 証明: | ISO |
| モデル番号: | PR54R RCハンマードリルビット |
| 最小注文数量: | 1 |
|---|---|
| 受渡し時間: | 20-30 |
| 供給の能力: | 3000 |
| 製造プロセス: | 鍛造 | 材料: | 合金鋼 |
|---|---|---|---|
| アドバンテージ: | 高性能 | 色: | 要求ごと |
| 部品名: | DTHの穴あけ工具 | 使用法: | 穴のdrlling |
| ハイライト: | RC hammer drill bit for DTH hammer,reverse circulation drill bit for rock drilling,PR54R RC hammer bit with warranty |
||
| Attribute | Value |
|---|---|
| Manufacturing Process | Forging |
| Material | Alloy Steel |
| Advantage | High Performance |
| Color | Per Request |
| Parts Name | DTH Drill Bits |
| Usage | Hole Drilling |
RC series reverse circulation DTH Hammer is mainly used for deep exploration drilling and stope ore grade control. This reverse circulation drill bits are widely used in the following application fields:
Specifically designed to work with RC Hammers.
Other sizes available upon customer request. Customization available.
| Diameter mm | Diameter inch | No x Button diameter | Button angle | Flushing holes | Shroud Dia mm | Weight (kg) | Part No | |
|---|---|---|---|---|---|---|---|---|
| 136 | 5 3/8 | 8 x 16mm | 6x16+3x14 | 35 | 2 | 134 | 19.0 | PR54-136 |
| 140 | 5 1/2 | 8 x 16mm | 6x16+3x14 | 35 | 2 | 138 | 19.3 | PR54-140 |
| 143 | 5 5/8 | 8 x 16mm | 6x16+3x14 | 35 | 2 | 141 | 19.5 | PR54-143 |
| 146 | 5 3/4 | 8 x 16mm | 6x16+3x14 | 35 | 2 | 144 | 19.6 | PR54-146 |
