Name: High Quality QL50 130mm Shank Adaptor Drill Steel Foot Valve Carbide Tungsten Bit For Construction Quarry Top Hammer
Brand: KSQ Technologies (Beijing) Co. Ltd
SKU: QL50 130mm
Price: 165 USD
Availability: InStock

ホーム製品ロック掘削ツール

High Quality QL50 130mm Shank Adaptor Drill Steel Foot Valve Carbide Tungsten Bit For Construction Quarry Top Hammer

商品の詳細:

起源の場所:	中国
ブランド名:	MIROC
証明:	ISO
モデル番号:	QL50 130mm

お支払配送条件:

最小注文数量:	1
価格:	165
パッケージの詳細:	木製ケース
受渡し時間:	20-30
支払条件:	L/C、D/A、D/P、T/T、ウェスタンユニオン
供給の能力:	3000

連絡先

詳細製品概要

型番:	QL50-130mm	表面処理:	スプレーペイント
材料:	炭素鋼および超硬	ビットフェイス:	球面、凹面、平面
応用:	井戸掘削、採掘、採石、建設	DTH ハンマー:	QL50
色:	顧客の要求	重量(kg):	15
アドバンテージ:	高性能	使用法:	採掘削岩
ハイライト:	130mm shank adaptor drill bit , tungsten carbide hammer drill bit , construction quarry steel foot valve

High Quality QL50 130mm Shank Adaptor Drill Steel Foot Valve Carbide Tungsten Bit

Professional DTH bit designed for construction, quarry, and top hammer drilling applications.

DTH Bits for Mining & Blast Hole Drilling

Down-the-Hole (DTH) bits are essential components for mining, quarry drilling, water well drilling, and blast hole applications where high penetration rates and reliable performance are critical.

DTH bits are engineered for efficient rock penetration, extended service life, and stable operation in demanding hard rock environments.

Product Specifications

Bit Dia. (mm)	Bit Dia. (inch)	Front Buttons	Gauge Buttons	Flushing Holes	Weight (kg)	Part Number
Spherical Concave Face
130	5.125	4x14, 3x14	8x16	2	14.5	4148301347
133	5.25	4x14, 3x14	8x16	2	14.5	4148301348
140	5.5	4x14, 4x14	8x16	2	15.5	4148301349
146	5.75	4x14, 4x14	8x16	2	15.6	4148301350
152	6	4x16, 4x16	8x18	2	16.5	4148301351
Ballistic Convex Face
130	5.125	3x14, 4x14	9x16	3	14.5	4148301352
133	5.25	3x14, 4x14	9x16	3	14.5	4148301353
140	5.5	3x16, 4x16	9x16	3	15.5	4148301354
146	5.75	3x16, 4x16	9x16	3	15.6	4148301355
152	6	3x16, 5x16	9x18	3	16.5	4148301356
Spherical Flat Face
130	5.125	7x14	8x16	2	14.5	4148301357
133	5.25	7x14	8x16	2	14.5	4148301358
140	5.5	7x14	7x18	2	15.5	4148301359
140	5.5	8x14	9x16	3	15.5	4148301360
146	5.75	8x14	9x16	3	15.6	4148301361
152	6	8x16	9x18	3	16.5	4148301362

Design & Manufacturing

Materials: High-quality alloy steel with premium tungsten carbide buttons
Durability: Designed to withstand heavy impact drilling and abrasive rock formations
Optimized button arrangement: Improves energy distribution, maintains hole straightness, and reduces vibration

DTH Drilling System Advantages

In DTH systems, the hammer sits directly behind the bit, transferring impact energy efficiently to the rock surface. This design minimizes energy loss and boosts productivity compared to conventional methods.
